PT206 Series 4-20 ma Sanitary Ferrule Pressure Transducer for food Industry
Feature
● MEMS technology
● Germany sensor employed
● Perfect long term stability
● Digital Calibration
● OEM service provided
● CE certificate
Applications
● HVAC system
● Water filter
● Air conditioner control equipments
● Frequency water supply
● Water pump
● Building water supply
Description
PT 206 series sanitary pressure transmitters are designed for the measurement of viscous media pressure and level slots for hygienic requirements in the food, medical and other industries. The sensor components was treatment through special process, the formation of non-lead hole and cavity structure, to prevent viscous media on the sensor surface scale or clogging, at the same time, the product also have small size, light weight, high precision, high reliability and easy installation characteristics. The product meet the U.S. Food and Health Administration (FDA) 3A standard, can be widely used in food, beverage, beer, medical, petroleum, paper and other industries.
Speifications
| pressure medium | Sanitary Ferrule Pressure Transducer for food Industry |
| pressure ranges | 0~2...600bar |
| overload pressure | 150%FS |
| Broken Pressure | 300%FS |
| output signal | 4~20mA, 0~5V,0.5-4.5V , 0-10V , RS485 |
| accuracy | 1%FS , 2%FS (standard) |
| load resistance | RL = (U-10)/0.02(Ω) (4~20mA current output), ＞100KΩ (voltage output) |
| long term stability | 0.5%FS/year |
| supply voltage | 10~36V, 8-36V,6-24V, 12-24V ,5V |
| compensated temperature range | -10~80°c |
| operating temperature range | -40~+100°c |
| storage temperature range | -40~+120°c |
| insulation resistance | >100MΩ@ 50VDC |
| response time | <1ms |
| EMC | EMI:EN50081-1/-2, EMS:EN50082-2 |
| process connection | G1/4 ,R1/4,7/16-20UNF,M20*1.5,9/16-20UNF, NPT1/4. |
| electrical connection | DIN 43650 or others |
| material of wetted part | 1Cr18Ni9Ti |
| material of pressure membrane | 316L |
| material of housing | 1Cr18Ni9Ti,brass |
| weight | 90g |
Price, Package, Service
1, Price : EXW, FOB, CFR Xi'an
2, Payment: 100% T/T in advance .
3, Packing : standard export packing , including instructions and certificate
4, Leading time : 7-10 working days.
5, OEM avaliable
6, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
7. 7 days free replace & 1 year free repair for quality warranty
Packing:standard export packing , including instructions and certificate/ Carton Packing, Water Proof, Shock Resistance
